The ICODE® ILT supporting the ISO/IEC 18000-3 RFID for item management at 13,56 MHz and EPC™ Radio-Frequency Identity Protocols EPC Class-1 HF at 13.56 MHz. ICODE® ILT is designed for applications where reliable identification and high anti-collision rates are required with EPC memory.
ICODE® ILT and ICODE® ILT-M comes with up to 240-bit of EPC memory. Electronic Product Code (EPC) is defined according to the EPCglobal Tag Data Standard, as a unique universal identity for every physical object anywhere in the world.
The difference between ICODE® ILT and ICODE® ILT-M is mainly the user memory. ICODE® ILT-M comes with 512-bit user memory, where ICODE® ILT is designed with NO user memory.
Toys and Board Games
EPC Memory: Up to 240-bit of
TID: 96-bit tag identifier (TID) including 48-bit unique serial number
Operating frequency: 13.56 MHz
Forward link: 25 kbit/s to 100 kbit/s
Return link: 53 kbit/s to 848 kbit/s
Protocol: ISO/IEC 18000-3, EPC Class-1 HF, NFC Forum Tag 5 Type
Operating distance: up to 1.5 Meter
anti-collision: up to 800 tags/s
Input capacitance: 23.5 pF / 97 pF
EAS (Electronic Article Surveillance) functionality
Data retention: 50 years
Write endurance: 100,000 cycles
